The MCU modules provide analog inputs to interface mostly with static pressure sensors and inlet positions. This module has a backup system that can measure the actual static pressure and adjust the inlets position itself if communication with the controller fails, to guarantee the safety of the birds and the building.

​

Application:

• Current system uses MCU module to measure;

• 1 static pressure sensor;

• 4 inlet position;

• It can be configured to calculate inlet position via an internal timer and can control the open/close time to 0.1 seconds resolution.

This module provides WDT interface to switch to back up mode if communication fail.
